Фиксированные индукторы
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Материал - сердечник | Индуктивность | Допуск | Номинальный ток (Ампер) | Ток - Насыщение (Isat) | Экранирование | Сопротивление постоянному току (DCR) | Q @ Freq | Частота - саморезонансная | Номинальные значения | Рабочая температура | Частота индуктивности - Тест | Особенности | Тип крепления | Устройство поставщика Упаковка | Размер/измерение | Высота - в сидячем положении (макс.) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
33100CFIXED IND 10UH 7.6A 20 MOHM TH Murata Power Solutions Inc. |
0 |
|
Таблицы данных |
3300 | Radial, Vertical, 4 Leads (Open) | Tray | Active | Toroidal | - | 10 µH | ±15% | 7.6 A | - | Unshielded | 20mOhm Max | 3.4 @ 1MHz | 68MHz | - | -40°C ~ 125°C | 1 MHz | - | Through Hole | - | 1.142" L x 0.642" W (29.00mm x 16.30mm) | 1.220" (31.00mm) |
|
|
33221CFIXED IND 220UH 1.6A 102 MOHM TH Murata Power Solutions Inc. |
0 |
|
Таблицы данных |
3300 | Radial, Vertical, 4 Leads (Open) | Tray | Active | Toroidal | - | 220 µH | ±15% | 1.6 A | - | Unshielded | 102mOhm Max | 3.2 @ 800kHz | 2MHz | - | -40°C ~ 125°C | 800 kHz | - | Through Hole | - | 1.142" L x 0.642" W (29.00mm x 16.30mm) | 1.220" (31.00mm) |
|
|
33330CFIXED IND 33UH 4.2A 40 MOHM TH Murata Power Solutions Inc. |
0 |
|
Таблицы данных |
3300 | Radial, Vertical, 4 Leads (Open) | Tray | Active | Toroidal | - | 33 µH | ±15% | 4.2 A | - | Unshielded | 40mOhm Max | 3.5 @ 1MHz | 24MHz | - | -40°C ~ 125°C | 1 MHz | - | Through Hole | - | 1.142" L x 0.642" W (29.00mm x 16.30mm) | 1.220" (31.00mm) |
|
|
33681CFIXED IND 680UH 920MA 183MOHM TH Murata Power Solutions Inc. |
0 |
|
Таблицы данных |
3300 | Radial, Vertical, 4 Leads (Open) | Tray | Active | Toroidal | - | 680 µH | ±15% | 920 mA | - | Unshielded | 183mOhm Max | 0.64 @ 800kHz | 900kHz | - | -40°C ~ 125°C | 800 kHz | - | Through Hole | - | 1.142" L x 0.642" W (29.00mm x 16.30mm) | 1.220" (31.00mm) |
|
27682CFIXED IND 6.8UH 1.4A 130MOHM SMD Murata Power Solutions Inc. |
0 |
|
Таблицы данных |
2700 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 6.8 µH | ±20% | 1.4 A | - | Unshielded | 130mOhm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.354" L x 0.303" W (9.00mm x 7.70mm) | 0.065" (1.65mm) |
|
|
27103CFIXED IND 10UH 1.1A 150 MOHM SMD Murata Power Solutions Inc. |
0 |
|
Таблицы данных |
2700 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 10 µH | ±20% | 1.1 A | - | Unshielded | 150mOhm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.354" L x 0.303" W (9.00mm x 7.70mm) | 0.065" (1.65mm) |
|
|
27153CFIXED IND 15UH 900MA 230MOHM SMD Murata Power Solutions Inc. |
0 |
|
Таблицы данных |
2700 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 15 µH | ±20% | 900 mA | - | Unshielded | 230mOhm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.354" L x 0.303" W (9.00mm x 7.70mm) | 0.065" (1.65mm) |
|
|
27223CFIXED IND 22UH 750MA 300MOHM SMD Murata Power Solutions Inc. |
0 |
|
Таблицы данных |
2700 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 22 µH | ±20% | 750 mA | - | Unshielded | 300mOhm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.354" L x 0.303" W (9.00mm x 7.70mm) | 0.065" (1.65mm) |
|
|
27333CFIXED IND 33UH 600MA 450MOHM SMD Murata Power Solutions Inc. |
0 |
|
Таблицы данных |
2700 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 33 µH | ±20% | 600 mA | - | Unshielded | 450mOhm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.354" L x 0.303" W (9.00mm x 7.70mm) | 0.065" (1.65mm) |
|
|
27473CFIXED IND 47UH 500MA 700MOHM SMD Murata Power Solutions Inc. |
0 |
|
Таблицы данных |
2700 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 47 µH | ±20% | 500 mA | - | Unshielded | 700mOhm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.354" L x 0.303" W (9.00mm x 7.70mm) | 0.065" (1.65mm) |
