Одиночные, предварительно смещенные биполярные транзисторы
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип транзистора | Ток - Коллектор (Ic) (Макс.) | Напряжение - Коллектор-Эмиттер Пробой (Макс.) | Резистор - База (R1) | Резистор - Эмиттер База (R2) | Усиление постоянного тока (hFE) (Мин.) @ Ic, Vce | Насыщение Vce (Макс.) @ Ib, Ic | Ток - Коллектор Отсечка (Макс.) | Частота - Переход | Мощность - макс. | Марка | Квалификация | Тип крепления | Устройство поставщика Упаковка |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FJY3002RTRANS PREBIAS NPN 50V SOT523F Fairchild Semiconductor |
529,473 |
|
Таблицы данных |
- | SC-89, SOT-490 | Bulk | Active | NPN - Pre-Biased | 100 mA | 50 V | 10 kOhms | 10 kOhms | 30 @ 5mA, 5V | 300mV @ 500µA, 10mA | 100nA (ICBO) | 250 MHz | 200 mW | - | - | Surface Mount | SOT-523F |
|
FJNS4202RTATRANS PREBIAS PNP 50V TO92S Fairchild Semiconductor |
477,000 |
|
Таблицы данных |
- | TO-226-3, TO-92-3 Short Body | Bulk | Obsolete | PNP - Pre-Biased | 100 mA | 50 V | 10 kOhms | 10 kOhms | 30 @ 5mA, 5V | 300mV @ 500µA, 10mA | 100nA (ICBO) | 200 MHz | 300 mW | - | - | Through Hole | TO-92S |
|
FJX3007RTFTRANS PREBIAS NPN 50V SC70 Fairchild Semiconductor |
417,000 |
|
Таблицы данных |
- | SC-70, SOT-323 | Bulk | Active | NPN - Pre-Biased | 100 mA | 50 V | 22 kOhms | 47 kOhms | 68 @ 5mA, 5V | 300mV @ 500µA, 10mA | 100nA (ICBO) | 250 MHz | 200 mW | - | - | Surface Mount | SC-70 (SOT323) |
|
FJV3103RMTFTRANS PREBIAS NPN 50V SOT23-3 Fairchild Semiconductor |
244,400 |
|
Таблицы данных |
- | TO-236-3, SC-59, SOT-23-3 | Bulk | Active | NPN - Pre-Biased | 100 mA | 50 V | 22 kOhms | 22 kOhms | 56 @ 5mA, 5V | 300mV @ 500µA, 10mA | 100nA (ICBO) | 250 MHz | 200 mW | - | - | Surface Mount | SOT-23-3 |
|
FJNS3201RTATRANS PREBIAS NPN 50V TO92S Fairchild Semiconductor |
138,000 |
|
Таблицы данных |
- | TO-226-3, TO-92-3 Short Body | Bulk | Obsolete | NPN - Pre-Biased | 100 mA | 50 V | 4.7 kOhms | 4.7 kOhms | 20 @ 10mA, 5V | 300mV @ 500µA, 10mA | 100nA (ICBO) | 250 MHz | 300 mW | - | - | Through Hole | TO-92S |
|
|
FJN3309RTATRANS PREBIAS NPN 40V TO92-3 Fairchild Semiconductor |
126,000 |
|
Таблицы данных |
- | TO-226-3, TO-92-3 (TO-226AA) Formed Leads | Bulk | Obsolete | NPN - Pre-Biased | 100 mA | 40 V | 4.7 kOhms | - | 100 @ 1mA, 5V | 300mV @ 1mA, 10mA | 100nA (ICBO) | 250 MHz | 300 mW | - | - | Through Hole | TO-92-3 |
|
FJN4305RTATRANS PREBIAS PNP 50V TO92-3 Fairchild Semiconductor |
104,753 |
|
Таблицы данных |
- | TO-226-3, TO-92-3 (TO-226AA) Formed Leads | Bulk | Active | PNP - Pre-Biased | 100 mA | 50 V | 4.7 kOhms | 10 kOhms | 30 @ 5mA, 5V | 300mV @ 500µA, 10mA | 100nA (ICBO) | 200 MHz | 300 mW | - | - | Through Hole | TO-92-3 |
|
|
FJN3310RTATRANS PREBIAS NPN 40V TO92-3 Fairchild Semiconductor |
104,000 |
|
Таблицы данных |
- | TO-226-3, TO-92-3 (TO-226AA) Formed Leads | Bulk | Obsolete | NPN - Pre-Biased | 100 mA | 40 V | 10 kOhms | - | 100 @ 1mA, 5V | 300mV @ 1mA, 10mA | 100nA (ICBO) | 250 MHz | 300 mW | - | - | Through Hole | TO-92-3 |
|
FJV3101RLIMTFTRANS PREBIAS Fairchild Semiconductor |
102,000 |
|
- |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
FJV4101RMTFTRANS PREBIAS PNP 50V SOT23-3 Fairchild Semiconductor |
63,879 |
|
Таблицы данных |
- | TO-236-3, SC-59, SOT-23-3 | Bulk | Active | PNP - Pre-Biased | 100 mA | 50 V | 4.7 kOhms | 4.7 kOhms | 20 @ 10mA, 5V | 300mV @ 500µA, 10mA | 100nA (ICBO) | 200 MHz | 200 mW | - | - | Surface Mount | SOT-23-3 |
