Устройства защиты от перенапряжения (SPD)
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Упаковка | Состояние продукта | Тип | Форма | Количество полюсов | Напряжение - Непрерывная работа (Макс.) (MCOV) | Ток - Разряд (Ном.) (8/20 мкС) | Ток - Разряд (Макс.) (8/20 мкС) | Рабочая температура | Напряжение - Степень защиты (VPR) | Напряжение - Уровень защиты (VP) (2416) | Рабочая температура | Особенности | Тип крепления | Сертифицирующее агентство |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1220-10-I2-120M1SPD TYPE 2/TYPE 4 150VAC MCOV |
6 |
|
Таблицы данных |
1220 | Box | Active | Type 2, Type 4 | Module Only | 1 | 150VAC | 10 kA | 25 kA | 200 kA | 600 V | - | -40°C ~ 85°C | Remote Signaling Contacts, Thermally Protected | Surface Mount | cURus |
|
LSP05GI240SX3333SPD TYPE 2/TYPE 3 275VAC MCOV |
80 |
|
Таблицы данных |
LSP | Bulk | Active | Type 2, Type 3 | Module Only | 1 | 275VAC | 5 kA | 10 kA | - | - | 2.4 kV | -40°C ~ 85°C | Thermally Protected | Screw | CE, cURus, KEMA-KEUR, UL |
|
|
1220-10-I2-400M1SPD TYPE 2/TYPE 4 420VAC MCOV |
10 |
|
Таблицы данных |
1220 | Box | Active | Type 2, Type 4 | Module Only | 1 | 420VAC | 10 kA | 25 kA | 200 kA | 1.2 kV | - | -40°C ~ 85°C | Remote Signaling Contacts, Thermally Protected | Surface Mount | cURus |
|
|
LSP4-480SPD TYPE 5 550V MCOV 1 POLE |
63 |
|
Таблицы данных |
- | Box | Active | Type 5 | Module Only | 1 | 550V | 5 kA | 20 kA | - | - | - | 85°C | - | Chassis Mount | cURus |
|
|
LSP4-UNVSPD TYPE 5 320V MCOV 1 POLE |
28 |
|
Таблицы данных |
LSP4 | Box | Active | Type 5 | Module Only | 1 | 320V | 5 kA | 20 kA | - | - | - | 85°C | - | Chassis Mount | cURus |
|
|
1220-20-I4-120M3SPD TYPE 2/TYPE 4 150VAC MCOV |
10 |
|
Таблицы данных |
1220 | Box | Active | Type 2, Type 4 | Module Only | 1 | 150VAC | 20 kA | 50 kA | 200 kA | 600 V | - | -40°C ~ 85°C | Remote Signaling Contacts, Thermally Protected | Surface Mount | cURus |
|
|
LSP3-20L-480SPD 550V MCOV 1 POLE |
50 |
|
Таблицы данных |
- | Box | Active | - | Module Only | 1 | 550V | 10 kA | 20 kA | - | - | - | 85°C | - | Chassis Mount | cURus |
|
|
1220-20-I4-277M2SPD TYPE 1/TYPE 4 320VAC MCOV |
10 |
|
Таблицы данных |
1220 | Box | Active | Type 1, Type 4 | Module Only | 1 | 320VAC | 20 kA | 50 kA | 200 kA | 1 kV | - | -40°C ~ 85°C | Remote Signaling Contacts, Thermally Protected | Surface Mount | cURus |
|
|
1220-20-I4-277M3SPD TYPE 2/TYPE 4 320VAC MCOV |
10 |
|
Таблицы данных |
1220 | Box | Active | Type 2, Type 4 | Module Only | 1 | 320VAC | 20 kA | 50 kA | 200 kA | 1 kV | - | -40°C ~ 85°C | Remote Signaling Contacts, Thermally Protected | Surface Mount | cURus |
|
|
SPD-10S-277SSPD TYPE 2/TYPE 3 320VAC MCOV |
66 |
|
Таблицы данных |
SPD | Bulk | Active | Type 2, Type 3 | Module Only | 1 | 320VAC | 5 kA | 10 kA | - | - | - | -40°C ~ 85°C | Visual Life Indicator | Surface Mount | CE, cURus, EAC |
|
|
LSP3-20-UNVSPD 385V MCOV 1 POLE |
89 |
|
Таблицы данных |
- | Box | Active | - | Module Only | 1 | 385V | 10 kA | 20 kA | - | - | - | 85°C | - | Chassis Mount | cURus |
|
1354790000SPD 30VAC/42VDC MCOV 1 POLE |
10 |
|
Таблицы данных |
- | Bulk | Active | - | Module Only | 1 | 30VAC, 42VDC | 2.5 kA | 20 kA | - | - | - | -40°C ~ 70°C | - | DIN Rail | CE, EAC, UL |
|
LSP05480PMSPD TYPE 2/TYPE 4 510VAC MCOV |
65 |
|
Таблицы данных |
LSP | Tray | Active | Type 2, Type 4 | Module Only | 1 | 510VAC | 5 kA | 10 kA | - | - | 1.9 kV | -45°C ~ 85°C | Thermally Protected | Screw | CE, cURus, UL |
|
|
1220-20-I5-120M4SPD TYPE 2/TYPE 4 150VAC MCOV |
10 |
|
Таблицы данных |
1220 | Box | Active | Type 2, Type 4 | Module Only | 1 | 150VAC | 20 kA | 75 kA | 200 kA | 600 V | - | -40°C ~ 85°C | Remote Signaling Contacts, Thermally Protected | Surface Mount | cURus |
|
|
1220-20-I5-277M4SPD TYPE 2/TYPE 4 320VAC MCOV |
10 |
|
Таблицы данных |
1220 | Box | Active | Type 2, Type 4 | Module Only | 1 | 320VAC | 20 kA | 75 kA | 200 kA | 1 kV | - | -40°C ~ 85°C | Remote Signaling Contacts, Thermally Protected | Surface Mount | cURus |
|
|
1220-20-I4-400M3SPD TYPE 2/TYPE 4 420VAC MCOV |
10 |
|
Таблицы данных |
1220 | Box | Active | Type 2, Type 4 | Module Only | 1 | 420VAC | 20 kA | 50 kA | 200 kA | 1.5 kV | - | -40°C ~ 85°C | Remote Signaling Contacts, Thermally Protected | Surface Mount | cURus |
|
|
1220-20-I4-400M2SPD TYPE 1/TYPE 4 420VAC MCOV |
10 |
|
Таблицы данных |
1220 | Box | Active | Type 1, Type 4 | Module Only | 1 | 420VAC | 20 kA | 50 kA | 200 kA | 1.2 kV | - | -40°C ~ 85°C | Remote Signaling Contacts, Thermally Protected | Surface Mount | cURus |
|
|
1220-20-I4-480M3SPD TYPE 2/TYPE 4 550VAC MCOV |
10 |
|
Таблицы данных |
1220 | Box | Active | Type 2, Type 4 | Module Only | 1 | 550VAC | 20 kA | 50 kA | 200 kA | 1.5 kV | - | -40°C ~ 85°C | Remote Signaling Contacts, Thermally Protected | Surface Mount | cURus |
|
|
1220-20-I4-480M2SPD TYPE 1/TYPE 4 550VAC MCOV |
10 |
|
Таблицы данных |
1220 | Box | Active | Type 1, Type 4 | Module Only | 1 | 550VAC | 20 kA | 50 kA | 200 kA | 1.8 kV | - | -40°C ~ 85°C | Remote Signaling Contacts, Thermally Protected | Surface Mount | cURus |
|
|
2591010000SPD TYPE 2 300VAC MCOV 1 POLE |
7 |
|
Таблицы данных |
VPU AC II | Bulk | Active | Type 2 | Base + Module | 1 | 300VAC | 20 kA | 50 kA | 150 kA | 900 V | 1.5 kV | -40°C ~ 85°C | - | DIN Rail | CE |
