Поворотные потенциометры, реостаты
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Упаковка | Состояние продукта | Сопротивление (Ом) | Допуск | Мощность (Вт) | Встроенный переключатель | Количество оборотов | Особенности | Конусность | Количество групп | Тип регулировки | Температурный коэффициент | Вращение | Резистивный материал | Тип вывода | Тип привода | Длина привода | Диаметр привода | Резьба втулки | Тип крепления |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
3852A-282-502APOT 5K OHM 2W CERMET LINEAR |
0 |
|
Таблицы данных |
3852 | Bulk | Obsolete | 5k | ±10% | 2W | None | 1.0 | - | Linear | 1 | User Defined | ±150ppm/°C | 280° | Cermet | Solder Lug | Slotted | 0.875" (22.23mm) | 0.250" (6.35mm) | 3/8-32 | Panel Mount |
|
3852C-282-103APOT 10K OHM 2W CERMET LINEAR |
0 |
|
Таблицы данных |
3852 | Bulk | Obsolete | 10k | ±10% | 2W | None | 1.0 | - | Linear | 1 | User Defined | ±150ppm/°C | 280° | Cermet | Solder Lug | Slotted | 0.875" (22.23mm) | 0.125" (3.18mm) | 1/4-32 | Panel Mount |
|
3310C-002-103POT 10K OHM 1/4W PLASTIC LINEAR |
0 |
|
Таблицы данных |
Pro Audio 3310 | Bulk | Obsolete | 10k | ±20% | 0.25W, 1/4W | None | 1.0 | Sealed | Linear | 1 | Side Adjustment | ±1000ppm/°C | 300° | Conductive Plastic | PC Pins | Slotted | 0.500" (12.70mm) | 0.125" (3.18mm) | 1/4-32 | Panel Mount |
|
PCW1J-C24-BAB104POT 100K OHM 3/4W PLASTIC LINEAR |
0 |
|
Таблицы данных |
PC-Slimline | Tray | Obsolete | 100k | ±20% | 0.75W, 3/4W | None | 1.0 | - | Linear | 1 | Top Adjustment | ±1000ppm/°C | 300° | Conductive Plastic | PC Pins | Flatted | 0.750" (19.05mm) | 0.250" (6.35mm) | M9 x 0.75 | Panel Mount |
|
|
53RAD-R22-A25POT 1M OHM 1W CERMET LINEAR |
0 |
|
Таблицы данных |
Pro Audio 53 | Tray | Obsolete | 1M | ±10% | 1W | None | 1.0 | Sealed | Linear | 1 | User Defined | ±150ppm/°C | 290° | Cermet | Solder Lug | Slotted | 0.866" (22.00mm) | 0.236" (6.00mm) | M10 x 0.75 | Panel Mount |
|
RHS7K5POT 7.5K OHM 25W WIREWOUND LIN |
0 |
|
Таблицы данных |
H | Bulk | Active | 7.5k | ±10% | 25W | None | 1.0 | - | Linear | 1 | User Defined | - | 300° | Wirewound | Solder Lug | Flatted | 0.750" (19.05mm) | 0.250" (6.35mm) | 3/8-32 | Panel Mount |
|
|
51AEA-B28-B13POT 5K OHM 1/2W PLASTIC LINEAR |
0 |
|
Таблицы данных |
Pro Audio 51 | Bulk | Obsolete | 5k | ±20% | 0.5W, 1/2W | Detent | 1.0 | Sealed | Linear | 1 | Side Adjustment | ±1000ppm/°C | 290° | Conductive Plastic | PC Pins | Slotted | 0.875" (22.23mm) | 0.250" (6.35mm) | 3/8-32 | Panel Mount |
|
3862C-282-503APOT 50K OHM 1W CERMET LINEAR |
0 |
|
Таблицы данных |
3862 | Bulk | Obsolete | 50k | ±10% | 1W | None | 1.0 | - | Linear | 1 | User Defined | ±150ppm/°C | 295° | Cermet | Solder Lug | Slotted | 0.875" (22.23mm) | 0.125" (3.18mm) | 1/4-32 | Panel Mount |
|
|
3310C-012-103POT 10K OHM 1/4W PLASTIC LINEAR |
0 |
|
Таблицы данных |
Pro Audio 3310 | Bulk | Obsolete | 10k | ±20% | 0.25W, 1/4W | None | 1.0 | Sealed | Linear | 1 | Side Adjustment | ±1000ppm/°C | 300° | Conductive Plastic | PC Pins | Slotted | 0.750" (19.05mm) | 0.125" (3.18mm) | 1/4-32 | Panel Mount |
|
RV4LAYSA254CPOT 250K OHM 2W CARBON LOG |
0 |
|
Таблицы данных |
RV4 | Bulk | Active | 250k | ±10% | 2W | None | 1.0 | - | Logarithmic | 1 | User Defined | - | 314° | Carbon | Solder Lug | Slotted | 0.625" (15.88mm) | 0.249" (6.32mm) | 3/8-32 | Panel Mount |
|
KA1051S28POT 1M OHM 2W CARBON LOGARITHMIC |
0 |
|
Таблицы данных |
K | Bulk | Obsolete | 1M | ±10% | 2W | None | 1.0 | - | Logarithmic | 1 | User Defined | - | 314° | Carbon | Solder Lug | Slotted | 0.875" (22.23mm) | 0.249" (6.32mm) | 3/8-32 | Panel Mount |
|
3310H-104-104POT 100K OHM 1/4W PLASTIC LINEAR |
0 |
|
Таблицы данных |
Pro Audio 3310 | Tube | Obsolete | 100k | ±20% | 0.25W, 1/4W | Rotary, SPST | 1.0 | Sealed | Linear | 1 | Top Adjustment | ±1000ppm/°C | 300° | Conductive Plastic | PC Pins | Flatted | 0.500" (12.70mm) | 0.125" (3.18mm) | 1/4-32 | Panel Mount |
|
|
KB5021S28POT 5K OHM 2W CARBON R-LOG |
0 |
|
Таблицы данных |
K | Bulk | Active | 5k | ±10% | 2W | None | 1.0 | - | Reverse Logarithmic | 1 | User Defined | - | 314° | Carbon | Solder Lug | Slotted | 0.875" (22.23mm) | 0.249" (6.32mm) | 3/8-32 | Panel Mount |
|
KKA1021S28POT 1K OHM 2W CARBON LOGARITHMIC |
0 |
|
Таблицы данных |
KK | Bulk | Active | 1k | ±10% | 2W | None | 1.0 | - | Logarithmic | 2 | User Defined | - | 314° | Carbon | Solder Lug | Slotted | 0.875" (22.23mm) | 0.249" (6.32mm) | 3/8-32 | Panel Mount |
|
|
KKA1031S28POT 10K OHM 2W CARBON LOG |
0 |
|
Таблицы данных |
KK | Bulk | Active | 10k | ±10% | 2W | None | 1.0 | - | Logarithmic | 2 | User Defined | - | 314° | Carbon | Solder Lug | Slotted | 0.875" (22.23mm) | 0.249" (6.32mm) | 3/8-32 | Panel Mount |
|
|
KKB1021S28POT 1K OHM 2W CARBON R-LOG |
0 |
|
Таблицы данных |
KK | Bulk | Active | 1k | ±10% | 2W | None | 1.0 | - | Reverse Logarithmic | 2 | User Defined | - | 314° | Carbon | Solder Lug | Slotted | 0.875" (22.23mm) | 0.249" (6.32mm) | 3/8-32 | Panel Mount |
|
|
KKB1031S28POT 10K OHM 2W CARBON R-LOG |
0 |
|
Таблицы данных |
KK | Bulk | Active | 10k | ±10% | 2W | None | 1.0 | - | Reverse Logarithmic | 2 | User Defined | - | 314° | Carbon | Solder Lug | Slotted | 0.875" (22.23mm) | 0.249" (6.32mm) | 3/8-32 | Panel Mount |
|
3862C-122-253APOT 25K OHM 1W CERMET LINEAR |
0 |
|
Таблицы данных |
3862 | Bulk | Obsolete | 25k | ±10% | 1W | None | 1.0 | - | Linear | 1 | User Defined | ±150ppm/°C | 295° | Cermet | Solder Lug | Slotted | 0.375" (9.53mm) | 0.125" (3.18mm) | 1/4-32 | Panel Mount |
|
|
KB2531S28POT 25K OHM 2W CARBON R-LOG |
0 |
|
Таблицы данных |
K | Bulk | Active | 25k | ±10% | 2W | None | 1.0 | - | Reverse Logarithmic | 1 | User Defined | - | 314° | Carbon | Solder Lug | Slotted | 0.875" (22.23mm) | 0.249" (6.32mm) | 3/8-32 | Panel Mount |
|
|
KB1041S28POT 100K OHM 2W CARBON R-LOG |
0 |
|
Таблицы данных |
K | Bulk | Active | 100k | ±10% | 2W | None | 1.0 | - | Reverse Logarithmic | 1 | User Defined | - | 314° | Carbon | Solder Lug | Slotted | 0.875" (22.23mm) | 0.249" (6.32mm) | 3/8-32 | Panel Mount |
