БОМ
Триак, выходные оптоизоляторы SCR
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип выхода | Цепь пересечения нуля | Количество каналов | Напряжение - Изоляция | Напряжение - Выкл. | Статическое dV/dt (мин.) | Ток - светодиодный триггер (Ift) (макс.) | Ток - Вкл. состояние (It (RMS)) (макс.) | Ток - Удержание (Ih) | Время включения | Напряжение - прямое (Vf) (тип.) | Ток - постоянный ток вперед (If) (макс.) | Рабочая температура | Тип крепления | Устройство поставщика Упаковка | Сертифицирующее агентство |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
S21ME8YOPTOISOLATOR 5KV TRIAC 6DIP |
1,808 |
|
Таблицы данных |
- | - | Tube | Obsolete | Triac | Yes | 1 | 5000Vrms | 800 V | 500V/µs | 3mA | 100 mA | 3.5mA | 50µs (Max) | 1.2V | 15 mA | -30°C ~ 100°C | Through Hole | - | BSI, DEMKO, SEMKO, UR, VDE |
|
MOC3162TMTRIAC OUTPUT OPTOCOUPLER |
5,667 |
|
Таблицы данных |
- | 6-DIP (0.400", 10.16mm) | Tube | Obsolete | Triac | Yes | 1 | 4170Vrms | 600 V | 1kV/µs | 10mA | - | 500µA (Typ) | - | 1.3V | 60 mA | -40°C ~ 85°C | Through Hole | 6-DIP | UL |
|
|
MOC3011SR2VMOPTOISOLATOR 4.17KV TRIAC 6SMD |
0 |
|
Таблицы данных |
- | 6-SMD, Gull Wing | Tape & Reel (TR) | Active | Triac | No | 1 | 4170Vrms | 250 V | - | 10mA | - | 100µA (Typ) | - | 1.15V | 60 mA | -40°C ~ 85°C | Surface Mount | 6-SMD | IEC/EN/DIN, UL |
|
FOD4218VOPTOISOLATOR 5KV TRIAC 6DIP |
990 |
|
- |
* | - | Tube | Discontinued at Digi-Key | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
.JPG)
|
TLP3064(D4TP1S,C,FX36 PB-F PHOTOCOUPLER SMD, VDE, |
991 |
|
Таблицы данных |
- | 6-DIP (0.300", 7.62mm), 5 Leads | Tape & Reel (TR) | Last Time Buy | Triac | Yes | 1 | 5000Vrms | 600 V | 200V/µs | 3mA | 100 mA | 600µA (Typ) | - | 1.4V | 30 mA | -40°C ~ 100°C | Through Hole | 6-DIP (Cut), 5 Lead | cUR, UR, VDE |
|
MOC3020MTRIAC OUTPUT OPTOCOUPLER, 5300V |
3,000 |
|
Таблицы данных |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
MOC3021SMTRIAC OUTPUT OPTOCOUPLER, 5300V |
7,795 |
|
Таблицы данных |
- | 6-SMD, Gull Wing | Bulk | Active | Triac | No | 1 | 4170Vrms | 400 V | - | 15mA | - | 100µA (Typ) | - | 1.15V | 60 mA | -40°C ~ 85°C | Surface Mount | 6-SMD | UL |
|
|
MOC3021TVMTRIAC OUTPUT OPTOCOUPLER, 5300V |
10,760 |
|
Таблицы данных |
- | 6-DIP (0.400", 10.16mm) | Bulk | Active | Triac | No | 1 | 4170Vrms | 400 V | - | 15mA | - | 100µA (Typ) | - | 1.15V | 60 mA | -40°C ~ 85°C | Through Hole | 6-DIP | IEC/EN/DIN, UL |
|
|
MOC3012MTRIAC OUTPUT OPTOCOUPLER, 5300V |
1,180 |
|
Таблицы данных |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
MOC3023VMTRIAC OUTPUT OPTOCOUPLER, 5300V |
8,077 |
|
Таблицы данных |
- | 6-DIP (0.300", 7.62mm) | Bulk | Active | Triac | No | 1 | 4170Vrms | 400 V | - | 5mA | - | 100µA (Typ) | - | 1.15V | 60 mA | -40°C ~ 85°C | Through Hole | 6-DIP | IEC/EN/DIN, UL |
|
|
MOC3010VMTRIAC OUTPUT OPTOCOUPLER, 5300V |
2,702 |
|
Таблицы данных |
- | 6-DIP (0.300", 7.62mm) | Bulk | Active | Triac | No | 1 | 4170Vrms | 250 V | - | 15mA | - | 100µA (Typ) | - | 1.15V | 60 mA | -40°C ~ 85°C | Through Hole | 6-DIP | IEC/EN/DIN, UL |
|
|
MOC3010SMTRIAC OUTPUT OPTOCOUPLER, 5300V |
1,494 |
|
Таблицы данных |
- | 6-SMD, Gull Wing | Bulk | Active | Triac | No | 1 | 4170Vrms | 250 V | - | 15mA | - | 100µA (Typ) | - | 1.15V | 60 mA | -40°C ~ 85°C | Surface Mount | 6-SMD | UL |
|
|
MOC3022SR2VMTRIAC OUTPUT OPTOCOUPLER, 5300V |
1,090 |
|
Таблицы данных |
- | 6-SMD, Gull Wing | Bulk | Active | Triac | No | 1 | 4170Vrms | 400 V | - | 10mA | - | 100µA (Typ) | - | 1.15V | 60 mA | -40°C ~ 85°C | Surface Mount | 6-SMD | IEC/EN/DIN, UL |
|
|
MOC3020SMTRIAC OUTPUT OPTOCOUPLER, 5300V |
2,587 |
|
Таблицы данных |
- | 6-SMD, Gull Wing | Bulk | Active | Triac | No | 1 | 4170Vrms | 400 V | - | 30mA | - | 100µA (Typ) | - | 1.15V | 60 mA | -40°C ~ 85°C | Surface Mount | 6-SMD | UL |
|
|
MOC3042MTRIAC OUTPUT OPTOCOUPLER WITH ZE |
135,951 |
|
Таблицы данных |
- | 6-DIP (0.300", 7.62mm) | Bulk | Active | Triac | Yes | 1 | 4170Vrms | 400 V | 1kV/µs | 10mA | - | 400µA (Typ) | - | 1.25V | 60 mA | -40°C ~ 85°C | Through Hole | 6-DIP | UL |
|
|
MOC3021SR2VMTRIAC OUTPUT OPTOCOUPLER, 5300V |
3,700 |
|
Таблицы данных |
- | 6-SMD, Gull Wing | Bulk | Active | Triac | No | 1 | 4170Vrms | 400 V | - | 15mA | - | 100µA (Typ) | - | 1.15V | 60 mA | -40°C ~ 85°C | Surface Mount | 6-SMD | IEC/EN/DIN, UL |
|
|
MOC3052SR2VMTRIAC OUTPUT OPTOCOUPLER, 7500V |
226,000 |
|
Таблицы данных |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
MOC3051SMTRIAC OUTPUT OPTOCOUPLER, 7500V |
16,010 |
|
Таблицы данных |
- | 6-SMD, Gull Wing | Bulk | Active | Triac | No | 1 | 4170Vrms | 600 V | 1kV/µs | 15mA | - | 220µA (Typ) | - | 1.18V | 60 mA | -40°C ~ 85°C | Surface Mount | 6-SMD | UR |
|
|
MOC3012TVMTRIAC OUTPUT OPTOCOUPLER, 5300V |
2,000 |
|
Таблицы данных |
- | 6-DIP (0.400", 10.16mm) | Bulk | Active | Triac | No | 1 | 4170Vrms | 250 V | - | 5mA | - | 100µA (Typ) | - | 1.15V | 60 mA | -40°C ~ 85°C | Through Hole | 6-DIP | IEC/EN/DIN, UL |
|
|
MOC3033SVMTRIAC OUTPUT OPTOCOUPLER WITH ZE |
3,443 |
|
Таблицы данных |
- | 6-SMD, Gull Wing | Bulk | Active | Triac | Yes | 1 | 4170Vrms | 250 V | 1kV/µs | 5mA | - | 400µA (Typ) | - | 1.25V | 60 mA | -40°C ~ 85°C | Surface Mount | 6-SMD | IEC/EN/DIN, UL |
