Логические выходные оптоизоляторы
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Количество каналов | Входы - Сторона 1/Сторона 2 | Напряжение - Изоляция | Устойчивость к синфазным переходным процессам (мин.) | Тип входа | Тип выхода | Ток - выход/канал | Скорость передачи данных | Задержка распространения tpLH / tpHL (макс.) | Время нарастания/спада (тип.) | Напряжение - прямое (Vf) (тип.) | Ток - постоянный ток вперед (If) (макс.) | Напряжение - Питание | Марка | Квалификация | Рабочая температура | Тип крепления | Устройство поставщика Упаковка |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ACPL-563KL-200OPTOISO 1.5KV 2CH OPEN COLL 8DIP |
0 |
|
Таблицы данных |
- | 8-CDIP (0.300", 7.62mm) | Tube | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | - | - | -55°C ~ 125°C | Through Hole | 8-DIP |
|
ACPL-563KL-300OPTOISO 1.5KV OPEN COLL 8DIP GW |
0 |
|
Таблицы данных |
- | 8-CSMD, Gull Wing | Tube | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | - | - | -55°C ~ 125°C | Surface Mount | 8-DIP Gull Wing |
|
5962-0824202KPAOPTOISO 1.5KV 2CH OPEN COLL 8DIP |
0 |
|
Таблицы данных |
- | 8-DIP (0.300", 7.62mm) | Tube | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | - | - | -55°C ~ 125°C | Through Hole | 8-DIP |
|
|
5962-0824202KPCOPTOISO 1.5KV 2CH OPEN COLL 8DIP |
0 |
|
Таблицы данных |
- | 8-DIP (0.300", 7.62mm) | Tube | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | - | - | -55°C ~ 125°C | Through Hole | 8-DIP |
|
5962-0824202KXAOPTOISO 1.5KV OPEN COLL 8DIP GW |
0 |
|
Таблицы данных |
- | 8-SMD, Gull Wing | Tube | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | - | - | -55°C ~ 125°C | Surface Mount | 8-DIP Gull Wing |
|
|
5962-0824202KYAOPTOISO 1.5KV 2CH OPEN COLL 8SMD |
0 |
|
Таблицы данных |
- | 8-SMD Butt Joint | Tube | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | - | - | -55°C ~ 125°C | Surface Mount | 8-DIP Butt Joint |
|
|
5962-0824202KYCOPTOISO 1.5KV 2CH OPEN COLL 8SMD |
0 |
|
Таблицы данных |
- | 8-SMD Butt Joint | Tube | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | - | - | -55°C ~ 125°C | Surface Mount | 8-DIP Butt Joint |
|
|
HCPL-540KOPTOISO 1.5KV TRI-STATE 8DIP |
0 |
|
Таблицы данных |
- | 8-DIP (0.300", 7.62mm) | Bulk | Active | 1 | 1/0 | 1500VDC | 500V/µs | DC | Tri-State | 25 mA | 40Mbps | 60ns, 60ns | 15ns, 10ns | 1.35V | 10mA | 4.75V ~ 5.25V | - | - | -55°C ~ 125°C | Through Hole | 8-DIP |
|
|
HCPL-540K-100OPTOISO 1.5KV TRI-STATE 8SMD |
0 |
|
Таблицы данных |
- | 8-CSMD, Gull Wing | Bulk | Active | 1 | 1/0 | 1500VDC | 500V/µs | DC | Tri-State | 25 mA | 40Mbps | 60ns, 60ns | 15ns, 10ns | 1.35V | 10mA | 4.75V ~ 5.25V | - | - | -55°C ~ 125°C | Surface Mount | 8-SMD Butt Joint |
|
|
HCPL-540K-300OPTOISO 1.5KV TRI-STATE 8DIP GW |
0 |
|
Таблицы данных |
- | 8-CSMD, Gull Wing | Bulk | Active | 1 | 1/0 | 1500VDC | 500V/µs | DC | Tri-State | 25 mA | 40Mbps | 60ns, 60ns | 15ns, 10ns | 1.35V | 10mA | 4.75V ~ 5.25V | - | - | -55°C ~ 125°C | Surface Mount | 8-DIP Gull Wing |
|
|
HCPL-540K#200OPTOISO 1.5KV TRI-STATE 8DIP |
0 |
|
Таблицы данных |
- | 8-DIP (0.300", 7.62mm) | Bulk | Active | 1 | 1/0 | 1500VDC | 500V/µs | DC | Tri-State | 25 mA | 40Mbps | 60ns, 60ns | 15ns, 10ns | 1.35V | 10mA | 4.75V ~ 5.25V | - | - | -55°C ~ 125°C | Through Hole | 8-DIP |
|
|
5962-8957002KPAOPTOISO 1.5KV TRI-STATE 8DIP |
0 |
|
Таблицы данных |
- | 8-DIP (0.300", 7.62mm) | Tube | Active | 1 | 1/0 | 1500VDC | 500V/µs | DC | Tri-State | 25 mA | 40Mbps | 60ns, 60ns | 15ns, 10ns | 1.35V | 10mA | 4.75V ~ 5.25V | - | - | -55°C ~ 125°C | Through Hole | 8-DIP |
|
|
5962-8957002KPCOPTOISO 1.5KV TRI-STATE 8DIP |
0 |
|
Таблицы данных |
- | 8-DIP (0.300", 7.62mm) | Tube | Active | 1 | 1/0 | 1500VDC | 500V/µs | DC | Tri-State | 25 mA | 40Mbps | 60ns, 60ns | 15ns, 10ns | 1.35V | 10mA | 4.75V ~ 5.25V | - | - | -55°C ~ 125°C | Through Hole | 8-DIP |
|
|
5962-8957002KXAOPTOISO 1.5KV TRI-STATE 8DIP GW |
0 |
|
Таблицы данных |
- | 8-SMD, Gull Wing | Tube | Active | 1 | 1/0 | 1500VDC | 500V/µs | DC | Tri-State | 25 mA | 40Mbps | 60ns, 60ns | 15ns, 10ns | 1.35V | 10mA | 4.75V ~ 5.25V | - | - | -55°C ~ 125°C | Surface Mount | 8-DIP Gull Wing |
|
|
5962-8957002KYAOPTOISO 1.5KV TRI-STATE 8SMD |
0 |
|
Таблицы данных |
- | 8-SMD Butt Joint | Tube | Active | 1 | 1/0 | 1500VDC | 500V/µs | DC | Tri-State | 25 mA | 40Mbps | 60ns, 60ns | 15ns, 10ns | 1.35V | 10mA | 4.75V ~ 5.25V | - | - | -55°C ~ 125°C | Surface Mount | 8-DIP Butt Joint |
|
|
5962-8957002KYCOPTOISO 1.5KV TRI-STATE 8SMD |
0 |
|
Таблицы данных |
- | 8-SMD Butt Joint | Tube | Active | 1 | 1/0 | 1500VDC | 500V/µs | DC | Tri-State | 25 mA | 40Mbps | 60ns, 60ns | 15ns, 10ns | 1.35V | 10mA | 4.75V ~ 5.25V | - | - | -55°C ~ 125°C | Surface Mount | 8-DIP Butt Joint |
|
HCPL-643KOPTOISO 1.5KV PUSH PULL 20LCCC |
0 |
|
Таблицы данных |
- | 20-CLCC | Bulk | Active | 2 | 2/0 | 1500VDC | 500V/µs | DC | Push-Pull, Totem Pole | 25 mA | 40Mbps | 60ns, 60ns | 15ns, 10ns | 1.35V | 10mA | 4.75V ~ 5.25V | - | - | -55°C ~ 125°C | Surface Mount | 20-LCCC (8.89x8.89) |
|
|
5962-8957104K2AOPTOISO 1.5KV PUSH PULL 20LCCC |
0 |
|
Таблицы данных |
- | 20-CLCC | Tube | Active | 2 | 2/0 | 1500VDC | 500V/µs | DC | Push-Pull, Totem Pole | 25 mA | 40Mbps | 60ns, 60ns | 15ns, 10ns | 1.35V | 10mA | 4.75V ~ 5.25V | - | - | -55°C ~ 125°C | Surface Mount | 20-LCCC (8.89x8.89) |
|
|
HCPL-520KOPTOISO 1.5KV TRI-STATE 8DIP |
0 |
|
Таблицы данных |
- | 8-CDIP (0.300", 7.62mm) | Bulk | Active | 1 | 1/0 | 1500VDC | 1kV/µs | DC | Tri-State | 15 mA | 5MBd | 350ns, 350ns | 45ns, 10ns | 1.3V | 8mA | 4.5V ~ 20V | - | - | -55°C ~ 125°C | Through Hole | 8-DIP |
|
|
HCPL-520K-100OPTOISO 1.5KV TRI-STATE 8SMD |
0 |
|
Таблицы данных |
- | 8-SMD Butt Joint | Bulk | Active | 1 | 1/0 | 1500VDC | 1kV/µs | DC | Tri-State | 15 mA | 5MBd | 350ns, 350ns | 45ns, 10ns | 1.3V | 8mA | 4.5V ~ 20V | - | - | -55°C ~ 125°C | Surface Mount | 8-DIP Butt Joint |
