БОМ
Фиксированные индукторы
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Материал - сердечник | Индуктивность | Допуск | Номинальный ток (Ампер) | Ток - Насыщение (Isat) | Экранирование | Сопротивление постоянному току (DCR) | Q @ Freq | Частота - саморезонансная | Номинальные значения | Рабочая температура | Частота индуктивности - Тест | Особенности | Тип крепления | Устройство поставщика Упаковка | Размер/измерение | Высота - в сидячем положении (макс.) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
B82144B1152K000HF CHOKE EPCOS - TDK Electronics |
0 |
|
Таблицы данных |
B82144B1 | Axial | Tape & Reel (TR) | Active | Wirewound | Ferrite | 1.5 µH | ±10% | 2.3 A | - | Unshielded | 70mOhm Max | 25 @ 7.96MHz | 180MHz | - | -55°C ~ 125°C | 7.96 MHz | - | Through Hole | Axial | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) | - |
|
|
B82144F1153K009FIXED IND 15UH 1.4A 0.22OHM TH EPCOS - TDK Electronics |
0 |
|
Таблицы данных |
B82144F1 | Axial | Tape & Box (TB) | Active | Wirewound | Ferrite | 15 µH | ±10% | 1.4 A | - | Unshielded | 220mOhm Max | 60 @ 2.52MHz | 17MHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | Axial | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) | - |
|
|
B82144F1152K000FIXED IND 1.5UH 2.3A 0.07OHM TH EPCOS - TDK Electronics |
0 |
|
Таблицы данных |
B82144F1 | Axial | Tape & Reel (TR) | Active | Wirewound | Ferrite | 1.5 µH | ±10% | 2.3 A | - | Unshielded | 70mOhm Max | 25 @ 7.96MHz | 180MHz | - | -55°C ~ 125°C | 1 MHz | - | Through Hole | Axial | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) | - |
|
|
B82144F1153K000FIXED IND 15UH 1.4A 0.22OHM TH EPCOS - TDK Electronics |
0 |
|
Таблицы данных |
B82144F1 | Axial | Tape & Reel (TR) | Active | Wirewound | Ferrite | 15 µH | ±10% | 1.4 A | - | Unshielded | 220mOhm Max | 60 @ 2.52MHz | 17MHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | Axial | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) | - |
|
|
B82144B1153K000HF CHOKE EPCOS - TDK Electronics |
0 |
|
Таблицы данных |
B82144B1 | Axial | Tape & Reel (TR) | Active | Wirewound | Ferrite | 15 µH | ±10% | 1.4 A | - | Unshielded | 220mOhm Max | 60 @ 2.52MHz | 17MHz | - | -55°C ~ 125°C | 2.52 MHz | - | Through Hole | Axial | 0.256" Dia x 0.362" L (6.50mm x 9.20mm) | - |
|
|
B82144F1152K009FIXED IND 1.5UH 2.3A 0.07OHM TH EPCOS - TDK Electronics |
0 |
|
Таблицы данных |
B82144F1 | Axial | Tape & Box (TB) | Active | Wirewound | Ferrite | 1.5 µH | ±10% | 2.3 A | - | Unshielded | 70mOhm Max | 25 @ 7.96MHz | 180MHz | - | -55°C ~ 125°C | 1 MHz | - | Through Hole | Axial | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) | - |
|
B82144B1476J000FIXED IND 47MH 30MA 230 OHM TH EPCOS - TDK Electronics |
0 |
|
Таблицы данных |
LBC | Radial, Vertical Cylinder | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 47 mH | ±5% | 30 mA | - | Unshielded | 230Ohm Max | 40 @ 79.6kHz | 260kHz | - | -55°C ~ 125°C | 10 kHz | - | Through Hole | - | 0.256" Dia (6.50mm) | 0.571" (14.50mm) |
|
|
B82144B1686J000FIXED IND 68MH 25MA 290 OHM TH EPCOS - TDK Electronics |
0 |
|
Таблицы данных |
LBC | Radial, Vertical Cylinder | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 68 mH | ±5% | 25 mA | - | Unshielded | 290Ohm Max | 40 @ 79.6kHz | 200kHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.256" Dia (6.50mm) | 0.571" (14.50mm) |
|
|
B82144F1106J009FIXED IND 10MH 85MA 42OHM TH EPCOS - TDK Electronics |
0 |
|
Таблицы данных |
B82144F1 | Axial | Tape & Box (TB) | Active | Wirewound | Ferrite | 10 mH | ±5% | 85 mA | - | Unshielded | 42Ohm Max | 50 @ 79.6kHz | 750kHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | Axial | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) | - |
|
|
B82144F1156J000FIXED IND 15MH 50MA 75OHM TH EPCOS - TDK Electronics |
0 |
|
Таблицы данных |
B82144F1 | Axial | Tape & Reel (TR) | Active | Wirewound | Ferrite | 15 mH | ±5% | 50 mA | - | Unshielded | 75Ohm Max | 50 @ 79.6kHz | 500kHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | Axial | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) | - |
