Фиксированные индукторы
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Материал - сердечник | Индуктивность | Допуск | Номинальный ток (Ампер) | Ток - Насыщение (Isat) | Экранирование | Сопротивление постоянному току (DCR) | Q @ Freq | Частота - саморезонансная | Номинальные значения | Рабочая температура | Частота индуктивности - Тест | Особенности | Тип крепления | Устройство поставщика Упаковка | Размер/измерение | Высота - в сидячем положении (макс.) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HFW1V2818H330KIND HC 33UH 8.7A SMD Eaton - Electronics Division |
0 |
|
Таблицы данных |
HFW1V28xxH | 3-SMD, Gull Wing | Tape & Reel (TR) | Active | Wirewound | Ferrite | 33 µH | ±10% | 28 A | 8.7A | Unshielded | 2.86mOhm Max | - | 8.7MHz | - | -40°C ~ 125°C | 500 kHz | - | Surface Mount | 3-SMD | 1.098" L x 0.780" W (27.90mm x 19.80mm) | 0.700" (17.78mm) |
|
HC7-1R5-RFIXED IND 1.5UH 14.2A 4.3MOHM SM Eaton - Electronics Division |
0 |
|
Таблицы данных |
HC7 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Iron Powder | 1.5 µH | ±20% | 14.2 A | 28.8A | Unshielded | 4.3mOhm Max | - | - | - | -40°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.543" L x 0.512" W (13.80mm x 13.00mm) | 0.217" (5.50mm) |
|
|
HC8LP-4R5-RFIXED IND 4.5UH 6.5A 27.6MOHM SM Eaton - Electronics Division |
0 |
|
Таблицы данных |
HC8LP | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Iron Powder | 4.5 µH | ±20% | 6.5 A | 10A | Unshielded | 27.6mOhm Max | - | - | - | -40°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.429" L x 0.409" W (10.90mm x 10.40mm) | 0.138" (3.50mm) |
|
|
HC8LP-6R9-RFIXED IND 6.9UH 5.2A 42.8MOHM SM Eaton - Electronics Division |
0 |
|
Таблицы данных |
HC8LP | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Iron Powder | 6.9 µH | ±20% | 5.2 A | 8.1A | Unshielded | 42.8mOhm Max | - | - | - | -40°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.429" L x 0.409" W (10.90mm x 10.40mm) | 0.138" (3.50mm) |
|
HC8LP-3R5-RFIXED IND 3.5UH 6.9A 24.5MOHM SM Eaton - Electronics Division |
0 |
|
Таблицы данных |
HC8LP | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Iron Powder | 3.5 µH | ±20% | 6.9 A | 11.4A | Unshielded | 24.5mOhm Max | - | - | - | -40°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.429" L x 0.409" W (10.90mm x 10.40mm) | 0.138" (3.50mm) |
|
|
HC8LP-5R6-RFIXED IND 5.6UH 5.5A 38.9MOHM SM Eaton - Electronics Division |
0 |
|
Таблицы данных |
HC8LP | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Iron Powder | 5.6 µH | ±20% | 5.5 A | 9A | Unshielded | 38.9mOhm Max | - | - | - | -40°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.429" L x 0.409" W (10.90mm x 10.40mm) | 0.138" (3.50mm) |
|
|
HC8LP-8R2-RFIXED IND 8.2UH 4.5A 58 MOHM SMD Eaton - Electronics Division |
0 |
|
Таблицы данных |
HC8LP | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Iron Powder | 8.2 µH | ±20% | 4.5 A | 7.4A | Unshielded | 58mOhm Max | - | - | - | -40°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.429" L x 0.409" W (10.90mm x 10.40mm) | 0.138" (3.50mm) |
|
HC8-150-RFIXED IND 15UH 4.1A 68.6MOHM SMD Eaton - Electronics Division |
0 |
|
Таблицы данных |
HC8 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Iron Powder | 15 µH | ±20% | 4.1 A | 7.4A | Unshielded | 68.6mOhm Max | - | - | - | -40°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.429" L x 0.409" W (10.90mm x 10.40mm) | 0.157" (4.00mm) |
|
|
HC8-2R6-RFIXED IND 2.6UH 10.2A 11.4 MOHM Eaton - Electronics Division |
0 |
|
Таблицы данных |
HC8 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Iron Powder | 2.6 µH | ±20% | 10.2 A | 17.7A | Unshielded | 11.4mOhm Max | - | - | - | -40°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.429" L x 0.409" W (10.90mm x 10.40mm) | 0.157" (4.00mm) |
|
|
HC8-5R6-RFIXED IND 5.6UH 7.3A 26.3MOHM SM Eaton - Electronics Division |
0 |
|
Таблицы данных |
HC8 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Iron Powder | 5.6 µH | ±20% | 7.3 A | 12.1A | Unshielded | 26.3mOhm Max | - | - | - | -40°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.429" L x 0.409" W (10.90mm x 10.40mm) | 0.157" (4.00mm) |
