Фиксированные индукторы
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Материал - сердечник | Индуктивность | Допуск | Номинальный ток (Ампер) | Ток - Насыщение (Isat) | Экранирование | Сопротивление постоянному току (DCR) | Q @ Freq | Частота - саморезонансная | Номинальные значения | Рабочая температура | Частота индуктивности - Тест | Особенности | Тип крепления | Устройство поставщика Упаковка | Размер/измерение | Высота - в сидячем положении (макс.) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SDCHA1V8040-820-RIND SMD POWER 82.0UH 1.4A Eaton - Electronics Division |
690 |
|
Таблицы данных |
SDCHA1V80 | Nonstandard | Tape & Reel (TR) | Active | - | Nickel Zinc Ferrite (NiZn) | 82 µH | ±20% | 1.4 A | 1.6A | Shielded | 230mOhm | - | 8.5MHz | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.157" (4.00mm) |
|
DR1050-681-RFIXED IND 680UH 560MA 1.369 OHM Eaton - Electronics Division |
987 |
|
Таблицы данных |
DR1050 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 680 µH | ±30% | 560 mA | 550mA | Shielded | 1.369Ohm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.413" L x 0.406" W (10.50mm x 10.30mm) | 0.197" (5.00mm) |
|
EXL1V0402-3R3-RFIXED IND 3.3UH 5.5A 38.3MOHM SM Eaton - Electronics Division |
256 |
|
Таблицы данных |
EXL1V0402 | Nonstandard | Tape & Reel (TR) | Active | Molded | Iron Powder | 3.3 µH | ±20% | 5.5 A | 4.4A | Shielded | 38.3mOhm Max | - | 26MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.173" L x 0.173" W (4.40mm x 4.40mm) | 0.083" (2.10mm) |
|
|
EXL1V0503-R15-RFIXED IND 150NH 22.2A 2.31 MOHM Eaton - Electronics Division |
590 |
|
Таблицы данных |
EXL1V0503 | Nonstandard | Tape & Reel (TR) | Active | Molded | Iron Powder | 150 nH | ±20% | 22.2 A | 32.5A | Shielded | 2.31mOhm Max | - | 140MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.122" (3.10mm) |
|
|
EXL1V0503-R47-RFIXED IND 470NH 18.4A 4.13 MOHM Eaton - Electronics Division |
478 |
|
Таблицы данных |
EXL1V0503 | Nonstandard | Tape & Reel (TR) | Active | Molded | Iron Powder | 470 nH | ±20% | 18.4 A | 24A | Shielded | 4.13mOhm Max | - | 95MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.122" (3.10mm) |
|
|
EXL1V0503-R33-RFIXED IND 330NH 19.2A 3.52 MOHM Eaton - Electronics Division |
386 |
|
Таблицы данных |
EXL1V0503 | Nonstandard | Tape & Reel (TR) | Active | Molded | Iron Powder | 330 nH | ±20% | 19.2 A | 26A | Shielded | 3.52mOhm Max | - | 110MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.122" (3.10mm) |
|
|
EXL1V0503-R80-RFIXED IND 800NH 13.1A 5.65 MOHM Eaton - Electronics Division |
255 |
|
Таблицы данных |
EXL1V0503 | Nonstandard | Tape & Reel (TR) | Active | Molded | Iron Powder | 800 nH | ±20% | 13.1 A | 18A | Shielded | 5.65mOhm Max | - | 57MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.122" (3.10mm) |
|
|
EXL1V0503-1R0-RFIXED IND 1UH 12.2A 7.6MOHM SMD Eaton - Electronics Division |
72 |
|
Таблицы данных |
EXL1V0503 | Nonstandard | Tape & Reel (TR) | Active | Molded | Iron Powder | 1 µH | ±20% | 12.2 A | 14.3A | Shielded | 7.6mOhm Max | - | 50MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.122" (3.10mm) |
|
EXLA1V0603-1R0-RIND MOLDED SHLD 1.0UH 18.0A Eaton - Electronics Division |
1,157 |
|
Таблицы данных |
EXLA1V06 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 1 µH | ±20% | 18 A | 18A | Shielded | 6.05mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.283" L x 0.272" W (7.20mm x 6.90mm) | 0.118" (3.00mm) |
|
DR1030-220-RFIXED IND 22UH 1.8A 114.6MOHM SM Eaton - Electronics Division |
1,010 |
|
Таблицы данных |
DR1030 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 22 µH | ±30% | 1.8 A | 2.19A | Shielded | 114.6mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.413" L x 0.406" W (10.50mm x 10.30mm) | 0.118" (3.00mm) |
