Фиксированные индукторы
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Материал - сердечник | Индуктивность | Допуск | Номинальный ток (Ампер) | Ток - Насыщение (Isat) | Экранирование | Сопротивление постоянному току (DCR) | Q @ Freq | Частота - саморезонансная | Номинальные значения | Рабочая температура | Частота индуктивности - Тест | Особенности | Тип крепления | Устройство поставщика Упаковка | Размер/измерение | Высота - в сидячем положении (макс.) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CSEB0660H-1R2MSMD MOLDING POWER CHOKE CODACA |
660 |
|
Таблицы данных |
CSEB0660H | Nonstandard | Cut Tape (CT) | Active | Molded | Metal Composite | 1.2 µH | ±20% | 17.3 A | 17.3A | Shielded | 5.5mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.262" L x 0.254" W (6.65mm x 6.45mm) | 0.240" (6.10mm) |
|
CSEB0770H-8R2MSMD MOLDING POWER CHOKE CODACA |
3,841 |
|
Таблицы данных |
CSEB0770H | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal Composite | 8.2 µH | ±20% | 9.5 A | 9.6A | Shielded | 19.5mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.311" L x 0.299" W (7.90mm x 7.60mm) | 0.280" (7.10mm) |
|
CSEB0730H-4R7MSMD MOLDING POWER CHOKE CODACA |
1,612 |
|
Таблицы данных |
CSEB0730H | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal Composite | 4.7 µH | ±20% | 9.2 A | 9A | Shielded | 25mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.311" L x 0.299" W (7.90mm x 7.60mm) | 0.126" (3.20mm) |
|
|
CSEB0770H-100MSMD MOLDING POWER CHOKE CODACA |
840 |
|
Таблицы данных |
CSEB0770H | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal Composite | 10 µH | ±20% | 9.1 A | 8.9A | Shielded | 23mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.311" L x 0.299" W (7.90mm x 7.60mm) | 0.280" (7.10mm) |
|
|
CSEB0770H-5R6MSMD MOLDING POWER CHOKE CODACA |
544 |
|
Таблицы данных |
CSEB0770H | Nonstandard | Cut Tape (CT) | Active | Molded | Metal Composite | 5.6 µH | ±20% | 11.5 A | 12A | Shielded | 13.5mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.311" L x 0.299" W (7.90mm x 7.60mm) | 0.280" (7.10mm) |
|
|
CSEB0730H-1R5MSMD MOLDING POWER CHOKE CODACA |
500 |
|
Таблицы данных |
CSEB0730H | Nonstandard | Cut Tape (CT) | Active | Molded | Metal Composite | 1.5 µH | ±20% | 17 A | 16A | Shielded | 6.6mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.311" L x 0.299" W (7.90mm x 7.60mm) | 0.126" (3.20mm) |
|
|
CSEB0730H-3R3MSMD MOLDING POWER CHOKE CODACA |
500 |
|
Таблицы данных |
CSEB0730H | Nonstandard | Cut Tape (CT) | Active | Molded | Metal Composite | 3.3 µH | ±20% | 10.1 A | 10.8A | Shielded | 19mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.311" L x 0.299" W (7.90mm x 7.60mm) | 0.126" (3.20mm) |
|
|
CSEB0770H-3R3MSMD MOLDING POWER CHOKE CODACA |
393 |
|
Таблицы данных |
CSEB0770H | Nonstandard | Cut Tape (CT) | Active | Molded | Metal Composite | 3.3 µH | ±20% | 15.3 A | 16A | Shielded | 8.8mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.311" L x 0.299" W (7.90mm x 7.60mm) | 0.280" (7.10mm) |
|
|
CSEB0770H-6R8MSMD MOLDING POWER CHOKE CODACA |
248 |
|
Таблицы данных |
CSEB0770H | Nonstandard | Cut Tape (CT) | Active | Molded | Metal Composite | 6.8 µH | ±20% | 10 A | 10A | Shielded | 16.9mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.311" L x 0.299" W (7.90mm x 7.60mm) | 0.280" (7.10mm) |
|
|
CSEB0730H-2R2MSMD MOLDING POWER CHOKE CODACA |
180 |
|
Таблицы данных |
CSEB0730H | Nonstandard | Cut Tape (CT) | Active | Molded | Metal Composite | 2.2 µH | ±20% | 15 A | 13A | Shielded | 10.6mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.311" L x 0.299" W (7.90mm x 7.60mm) | 0.126" (3.20mm) |
