Фиксированные индукторы
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Материал - сердечник | Индуктивность | Допуск | Номинальный ток (Ампер) | Ток - Насыщение (Isat) | Экранирование | Сопротивление постоянному току (DCR) | Q @ Freq | Частота - саморезонансная | Номинальные значения | Рабочая температура | Частота индуктивности - Тест | Особенности | Тип крепления | Устройство поставщика Упаковка | Размер/измерение | Высота - в сидячем положении (макс.) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SRP1250-1R0MFIXED IND 1UH 29A 2.5 MOHM SMD Bourns Inc. |
7,661 |
|
Таблицы данных |
SRP1250 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Iron | 1 µH | ±20% | 29 A | 50A | Shielded | 2.5mOhm Max | - | - | - | -55°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.547" L x 0.531" W (13.90mm x 13.50mm) | 0.232" (5.90mm) |
|
|
SRP1250-4R7MFIXED IND 4.7UH 12A 15 MOHM SMD Bourns Inc. |
4,265 |
|
Таблицы данных |
SRP1250 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Iron | 4.7 µH | ±20% | 12 A | 27A | Shielded | 15mOhm Max | - | - | - | -55°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.547" L x 0.531" W (13.90mm x 13.50mm) | 0.205" (5.20mm) |
|
5248-RCFIXED IND 68UH 5A 54 MOHM TH Bourns Inc. |
3,967 |
|
Таблицы данных |
5200 | Axial | Bulk | Active | Drum Core, Wirewound | Ferrite | 68 µH | ±20% | 5 A | - | Unshielded | 54mOhm Max | - | 4.5MHz | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | - | 0.560" Dia x 1.250" L (14.22mm x 31.75mm) | - |
|
SRP1245A-3R3MFIXED IND 3.3UH 15A 9.2 MOHM SMD Bourns Inc. |
3,813 |
|
Таблицы данных |
SRP1245A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Carbonyl Powder | 3.3 µH | ±20% | 15 A | 32A | Shielded | 9.2mOhm Max | 20 @ 100kHz | 22MHz | AEC-Q200 | -40°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.492" W (13.50mm x 12.50mm) | 0.197" (5.00mm) |
|
|
SRP1245A-2R2MFIXED IND 2.2UH 20A 5.5 MOHM SMD Bourns Inc. |
3,763 |
|
Таблицы данных |
SRP1245A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Carbonyl Powder | 2.2 µH | ±20% | 20 A | 32A | Shielded | 5.5mOhm Max | 20 @ 100kHz | 24MHz | AEC-Q200 | -40°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.492" W (13.50mm x 12.50mm) | 0.197" (5.00mm) |
|
|
SRP1245A-6R8MFIXED IND 6.8UH 11A 18.5MOHM SMD Bourns Inc. |
3,519 |
|
Таблицы данных |
SRP1245A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Carbonyl Powder | 6.8 µH | ±20% | 11 A | 21A | Shielded | 18.5mOhm Max | 20 @ 100kHz | 12MHz | AEC-Q200 | -40°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.492" W (13.50mm x 12.50mm) | 0.197" (5.00mm) |
|
|
SRP1245A-180MFIXED IND 18UH 7.5A 45 MOHM SMD Bourns Inc. |
2,642 |
|
Таблицы данных |
SRP1245A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Carbonyl Powder | 18 µH | ±20% | 7.5 A | 11A | Shielded | 45mOhm Max | 20 @ 100kHz | 7MHz | AEC-Q200 | -40°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.492" W (13.50mm x 12.50mm) | 0.197" (5.00mm) |
|
|
SRP1245A-4R7MFIXED IND 4.7UH 12A 15 MOHM SMD Bourns Inc. |
1,640 |
|
Таблицы данных |
SRP1245A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Carbonyl Powder | 4.7 µH | ±20% | 12 A | 27A | Shielded | 15mOhm Max | 20 @ 100kHz | 15MHz | AEC-Q200 | -40°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.492" W (13.50mm x 12.50mm) | 0.197" (5.00mm) |
|
|
SRP1245A-100MFIXED IND 10UH 9A 25.5 MOHM SMD Bourns Inc. |
1,435 |
|
Таблицы данных |
SRP1245A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Carbonyl Powder | 10 µH | ±20% | 9 A | 16A | Shielded | 25.5mOhm Max | 20 @ 100kHz | 10MHz | AEC-Q200 | -40°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.492" W (13.50mm x 12.50mm) | 0.197" (5.00mm) |
|
|
SRP1245A-1R0MFIXED IND 1UH 29A 2.5 MOHM SMD Bourns Inc. |
1,047 |
|
Таблицы данных |
SRP1245A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Carbonyl Powder | 1 µH | ±20% | 29 A | 50A | Shielded | 2.5mOhm Max | 20 @ 100kHz | 40MHz | AEC-Q200 | -40°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.492" W (13.50mm x 12.50mm) | 0.197" (5.00mm) |
