Фиксированные индукторы
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Материал - сердечник | Индуктивность | Допуск | Номинальный ток (Ампер) | Ток - Насыщение (Isat) | Экранирование | Сопротивление постоянному току (DCR) | Q @ Freq | Частота - саморезонансная | Номинальные значения | Рабочая температура | Частота индуктивности - Тест | Особенности | Тип крепления | Устройство поставщика Упаковка | Размер/измерение | Высота - в сидячем положении (макс.) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SCIH1040HC-R82MFIXED IND 820NH 22A 3 MOHM SMD Signal Transformer |
0 |
|
Таблицы данных |
SCIH1040HC | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 820 nH | ±20% | 22 A | 30A | Shielded | 3mOhm Max | - | - | - | -55°C ~ 125°C | 200 kHz | - | Surface Mount | - | 0.453" L x 0.402" W (11.50mm x 10.20mm) | 0.157" (4.00mm) |
|
SC3340F-100FIXED IND 10UH 5.4A 40 MOHM SMD Signal Transformer |
0 |
|
Таблицы данных |
SC3340F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 10 µH | ±20% | 5.4 A | 8A | Unshielded | 40mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.530" L x 0.390" W (13.45mm x 9.90mm) | 0.450" (11.43mm) |
|
|
SC3340F-101FIXED IND 100UH 1.8A 220MOHM SMD Signal Transformer |
0 |
|
Таблицы данных |
SC3340F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 100 µH | ±20% | 1.8 A | 2.5A | Unshielded | 220mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.530" L x 0.390" W (13.45mm x 9.90mm) | 0.450" (11.43mm) |
|
|
SC3340F-102FIXED IND 1MH 580MA 2 OHM SMD Signal Transformer |
0 |
|
Таблицы данных |
SC3340F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 1 mH | ±20% | 580 mA | 800mA | Unshielded | 2Ohm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.530" L x 0.390" W (13.45mm x 9.90mm) | 0.450" (11.43mm) |
|
|
SC3340F-150FIXED IND 15UH 4.5A 50 MOHM SMD Signal Transformer |
0 |
|
Таблицы данных |
SC3340F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 15 µH | ±20% | 4.5 A | 7A | Unshielded | 50mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.530" L x 0.390" W (13.45mm x 9.90mm) | 0.450" (11.43mm) |
|
|
SC3340F-151FIXED IND 150UH 1.5A 340MOHM SMD Signal Transformer |
0 |
|
Таблицы данных |
SC3340F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 150 µH | ±20% | 1.5 A | 2A | Unshielded | 340mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.530" L x 0.390" W (13.45mm x 9.90mm) | 0.450" (11.43mm) |
|
|
SC3340F-1R5FIXED IND 1.5UH 13.5A 11MOHM SMD Signal Transformer |
0 |
|
Таблицы данных |
SC3340F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 1.5 µH | ±20% | 13.5 A | 18A | Unshielded | 11mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.530" L x 0.390" W (13.45mm x 9.90mm) | 0.450" (11.43mm) |
|
|
SC3340F-221FIXED IND 220UH 1.2A 440MOHM SMD Signal Transformer |
0 |
|
Таблицы данных |
SC3340F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 220 µH | ±20% | 1.2 A | 1.6A | Unshielded | 440mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.530" L x 0.390" W (13.45mm x 9.90mm) | 0.450" (11.43mm) |
|
|
SC3340F-2R2FIXED IND 2.2UH 11.5A 15MOHM SMD Signal Transformer |
0 |
|
Таблицы данных |
SC3340F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 2.2 µH | ±20% | 11.5 A | 14A | Unshielded | 15mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.530" L x 0.390" W (13.45mm x 9.90mm) | 0.450" (11.43mm) |
|
|
SC3340F-330FIXED IND 33UH 3.3A 80 MOHM SMD Signal Transformer |
0 |
|
Таблицы данных |
SC3340F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 33 µH | ±20% | 3.3 A | 4A | Unshielded | 80mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.530" L x 0.390" W (13.45mm x 9.90mm) | 0.450" (11.43mm) |
