Фиксированные индукторы
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Материал - сердечник | Индуктивность | Допуск | Номинальный ток (Ампер) | Ток - Насыщение (Isat) | Экранирование | Сопротивление постоянному току (DCR) | Q @ Freq | Частота - саморезонансная | Номинальные значения | Рабочая температура | Частота индуктивности - Тест | Особенности | Тип крепления | Устройство поставщика Упаковка | Размер/измерение | Высота - в сидячем положении (макс.) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
12LRS103CFIXED IND 10UH 3.4A 50 MOHM TH Murata Power Solutions Inc. |
294 |
|
Таблицы данных |
1200LRS | Radial, Vertical Cylinder, 4 Leads | Bulk | Active | Wirewound | - | 10 µH | ±20% | 3.4 A | - | Shielded | 50mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.413" Dia (10.50mm) | 0.335" (8.50mm) |
|
|
12LRS684CFIXED IND 680UH 500MA 1.65OHM TH Murata Power Solutions Inc. |
253 |
|
Таблицы данных |
1200LRS | Radial, Vertical Cylinder, 4 Leads | Bulk | Active | Wirewound | - | 680 µH | ±15% | 500 mA | - | Shielded | 1.65Ohm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.413" Dia (10.50mm) | 0.335" (8.50mm) |
|
|
12LRS685CFIXED IND 6.8MH 150MA 15 OHM TH Murata Power Solutions Inc. |
224 |
|
Таблицы данных |
1200LRS | Radial, Vertical Cylinder, 4 Leads | Bulk | Active | Wirewound | - | 6.8 mH | ±15% | 150 mA | - | Shielded | 15Ohm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.413" Dia (10.50mm) | 0.335" (8.50mm) |
|
|
12LRS225CFIXED IND 2.2MH 280MA 4.6 OHM TH Murata Power Solutions Inc. |
211 |
|
Таблицы данных |
1200LRS | Radial, Vertical Cylinder, 4 Leads | Bulk | Active | Wirewound | - | 2.2 mH | ±15% | 280 mA | - | Shielded | 4.6Ohm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.413" Dia (10.50mm) | 0.335" (8.50mm) |
|
|
12LRS106CFIXED IND 10MH 120MA 24 OHM TH Murata Power Solutions Inc. |
150 |
|
Таблицы данных |
1200LRS | Radial, Vertical Cylinder, 4 Leads | Bulk | Active | Wirewound | - | 10 mH | ±15% | 120 mA | - | Shielded | 24Ohm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.413" Dia (10.50mm) | 0.335" (8.50mm) |
|
|
12LRS474CFIXED IND 470UH 530MA 1.23OHM TH Murata Power Solutions Inc. |
105 |
|
Таблицы данных |
1200LRS | Radial, Vertical Cylinder, 4 Leads | Bulk | Active | Wirewound | - | 470 µH | ±15% | 530 mA | - | Shielded | 1.23Ohm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.413" Dia (10.50mm) | 0.335" (8.50mm) |
|
49101CFIXED IND 100UH 1.41A 343MOHM SM Murata Power Solutions Inc. |
365 |
|
Таблицы данных |
4900 | Nonstandard, 4 Lead | Tape & Reel (TR) | Active | Wirewound | - | 100 µH | - | 1.41 A | - | Shielded | 343mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - | 0.472" L x 0.472" W (12.00mm x 12.00mm) | 0.315" (8.00mm) |
|
|
49470CFIXED IND 47UH 2.1A 191MOHM SMD Murata Power Solutions Inc. |
355 |
|
Таблицы данных |
4900 | Nonstandard, 4 Lead | Tape & Reel (TR) | Active | Wirewound | - | 47 µH | - | 2.1 A | - | Shielded | 191mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - | 0.472" L x 0.472" W (12.00mm x 12.00mm) | 0.315" (8.00mm) |
|
26680CFIXED IND 68UH 1.11A 220MOHM SMD Murata Power Solutions Inc. |
500 |
|
Таблицы данных |
2600 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 68 µH | - | 1.11 A | - | Unshielded | 220mOhm Max | - | 8.37MHz | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.394" L x 0.354" W (10.00mm x 9.00mm) | 0.228" (5.80mm) |
|
22R476CFIXED IND 47MH 27MA 169.4 OHM TH Murata Power Solutions Inc. |
600 |
|
Таблицы данных |
2200R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | 47 mH | ±10% | 27 mA | - | Unshielded | 169.4Ohm Max | 90 @ 50kHz | 250kHz | - | -25°C ~ 70°C | 1 kHz | - | Through Hole | - | 0.256" Dia (6.50mm) | 0.413" (10.50mm) |
